Peplink Balance 580
Multi-WAN Routers - Now for every network!

Peplink Balance 580

Customers Please Note: We are restricted by the manufacturer from showing our lowest available price online. Call us Today at 844-294-0779 for a price quote!

Peplink Products
Peplink Multi-WAN Routers
Peplink Balance 580 #BPL-580
List Price: $3,499.00
Our Price: $3,324.00



Overview:

Fast

Combine the bandwidth of up to 13 Internet connections. Add and remove connections on the fly. Get speed when you need it. Pay less when you don’t.

Affordable

Break free of costly MPLS and other private circuits. Make the move to low-cost DSL, cable, satellite, and cellular connections without sacrificing a thing.

Reliable

Count on uptime and stability under the heaviest loads. Get the Balance and get connections that are rock-solid, fast, and reliable to the core.

The Peplink Balance multi-WAN router delivers Unbreakable VPN, SpeedFusion™ bandwidth bonding, and a host of other innovative technologies that let you take control of your WAN and improve Internet connectivity, all with one easy-to-manage device.

Connect Up to 13 Links from Multiple Providers

Connect any combination of DSL, cable, 4G LTE , and 3G links – up to 13 of them, from any ISP for anytime, anywhere connectivity. Whatever mix of connections you choose, the Balance intelligently distributes network traffic over all links connected anywhere on the network. You can also customize traffic flow and service availability with outbound policies and inbound load balancing settings, so you’re always in control. And with the Balance’s instant, automatic failover between links, you’re always online, too.

Reduce MPLS Costs up to 90%

With the Balance and SpeedFusion, you can bond multiple links connected anywhere on your network for VPNs that can add speed and reliability to expensive MPLS deployments or replace them entirely. Because you can combine a variety of affordable DSL, MPLS, cellular, and other WAN links into one secure, high-bandwidth tunnel, you get unprecedented reliability and performance while saving big on connectivity costs.

SpeedFusion-powered Unbreakable VPN

The Balance can bond affordable DSL, cable, cellular, and other WAN links into a single secure and fast VPN tunnel using SpeedFusion technology. Packet-level failover across WANs within VPN tunnels is instant and seamless, so your voice calls and RDP sessions won’t be interrupted when the Balance automatically switches between connections.

Monitor AP Usage Report and Create Guest Hotspot Easily from Your Balance

Our AP Controller makes it easy to manage your wireless network from a convenient, intuitive user interface built right into your Balance. You can easily manage your AP with graphical usage reports, and detailed event logs. Setting up a guest hotspot? The Balance’s included captive portal and splash screen help you provide a secure, fast, and customized Internet experience for everyone.

Benefits:


Break Internet Bandwidth Limits. Higher Speed. Extreme Reliability.

Internet Load Balancing

Boost network data rates, reliability, and flexibility while slashing connectivity costs with Peplink Internet Load Balancing technology. The Peplink Balance can distribute the traffic of up to 13 Internet links and route data using seven intelligent algorithms. It all adds up to high speeds and rock-solid dependability at a savings of up to 90% compared to solutions built on leased lines and other expensive links.

With the Peplink Balance, all your cable, DSL, leased line, cellular, and other links will work together to handle even the most demanding traffic, without lags or downtime. When you need more speed, add more connections.

Prioritize and Balance Traffic by Type or Application

The Peplink Balance incorporates 7 advanced link load balancing algorithms and customizable rules that put you in complete control of network data priorities. Just set your traffic priorities, including VoIP and custom application traffic, with a few clicks and let

Smarter Router. Faster Internet.

Peplink take care of the load balancing and optimization details – day in, day out.

Count on 100% Uptime with Automatic Failover

Automatic Failover keeps your network up and running by continually checking the health of all connected links and routing traffic around inactive or intermittent connections. You can even customize Automatic Failover's behavior, specifying conditional or dedicated backup links that dynamically respond to network status.

Replace MPLS with a Bonded VPN. SpeedFusion Shifts VPN Traffic into High Gear.

VPN for Branch Networking

Shift WAN data transfer, video delivery, VPNs, and more into overdrive with Peplink SpeedFusion. Peplink's patent-pending SpeedFusion true bandwidth bonding technology combines the bandwidth of up to 13 cable, DSL, 4G LTE/3G, and other links to drive high-speed, high-reliability, and high-security networking – all at a lower cost, with fewer maintenance headaches. Whether you’re transferring a single file or sharing dozens of documents, video feeds, and VoIP conversations, SpeedFusion teams up all your links to make it happen faster and more dependably.

SpeedFusion Seamless Failover

Maximum Performance. Minimum Hassle.

SpeedFusion increases performance across the board with intelligent bonding algorithms, advanced QoS, and video stream optimization. With SpeedFusion, your network stays up and running smoothly, without micromanagement, even when network traffic's at its heaviest.

Ditch Expensive MPLS.

Looking for an alternative to expensive leased lines? SpeedFusion bonds the bandwidth of up to 13 cable/DSL, 4G LTE/3G, WiMAX, and other Internet connections from multiple providers, boosting transfer speeds and reliability while saving you money compared to single-line MPLS.

Ditch Expensive MPLS - 5 Year comparsion of savings

Mobile Bandwidth Bonding. Turbocharge Mobile VPNs.

4G LTE/3G4G LTE/3G Bandwidth Bonding

SpeedFusion, the technology at the heart of every Balance Multi-WAN and MAX Mobile router, bonds the bandwidth from multiple cellular connections. You get faster and more reliable mobile VPNs in every application. Plus, all your data is secured by military-grade encryption, and data volume is monitored and controlled to keep you under your usage cap and within budget.

Get the Speed You Need on the Road.

SpeedFusion Bandwidth Bonding automatically aggregates all connected 4G LTE/3G/WiMAX links to give you fast data transfers, smooth HD video, and blazing performance wherever you go. Need more speed? Just add cellular connections and let SpeedFusion take care of the details.

Enjoy Wired Reliability without the Wires.

SpeedFusion bonds cellular connections from multiple providers, continuously monitoring link connectivity and automatically switching to healthy connections in the event of link failure. Your network stays up and running, and you stay open for business.

Bonded Wireless Links

Do More on the Road with SpeedFusion.

The speed, reliability, and security delivered by SpeedFusion open up a wide range of new mobile VPN applications in demanding, mission-critical fields, such as newscasting and public safety. In addition, transferring large files, such as those generated by digital production, photography, and POS activities, becomes practical and profitable wherever your mobile workforce roams.

All-in-One WLAN Solution. Manage hundreds of APs. Built-in Captive Portal.

Business WLAN Solution

Peplink’s business WLAN solution combines an enterprise-grade wireless access point and centralized access point management in one easy-to-use and affordable package. Now you can manage wireless LAN networks of up to 500 Pepwave AP One devices using a single Peplink Balance. With Peplink’s WLAN solution, all your mobile devices, including iPhones, iPads, and Android devices, get the same reliable Internet connection that you’ve come to expect from Peplink – without the wires!

Built-in WLAN Controller

Simplify your network management by controlling your AP One access points using a centralized admin interface built into the Peplink Balance. Just connect an AP One to the network and it will be discovered by the Balance automatically, allowing you manage and set-up your access point instantly!

Easy Wi-Fi Portal

Peplink’s WLAN solution features a built-in captive portal, which allows you to provide Wi-Fi hotspot service to your customers or Wi-Fi access to your guests in a corporate environment. From showing a splash screen for free users to accept service terms to creating a user login for your paid customers, you can easily customize your Wi-Fi portal in just a few clicks.

Unified Network Management

With our WLAN solution, you can manage all network connections, local client access, and user bandwidth policy using one single package. Administrators can monitor and generate reports on AP activity and bandwidth consumption, giving you complete and easy control over your network.

Maintenance:


Installation Without Headache, Maintenance Without Sweat.

Network configuration can be complicated. Peplink Balance is equipped with Drop-In Mode which transparently adds the multi-WAN router into your network without modifying other network hardware configurations. Setting up the Balance is easier than you think, with no more pressure for on command recall. Our Web Admin allows you to modify every configuration easily and intuitively.

your internet watchdogYour Internet Watchdog.

Peplink Balance will send out an email notification when an Internet link is down. A free reporting service is also available with each Peplink Balance, giving you reports on usage and uptime of your Internet links. Peplink Balance also supports major reporting protocol such as Syslog and SNMP, letting you monitor your network with the utility of your choice.

Need Help? Don't Panic.

Need help? don't panicPeplink has provided extensive support coverage to assist you in using the Peplink Balance. Knowledge Base contains tips and guide to common questions. If that isn't enough, the complementary email support will bring your attention to our expert support staff. Give yourself extra peace of mind by purchasing the Peplink TotalCare and gain access to telephone support, firmware upgrades, and protect your investment when the unpredictable occurs.

Product Comparision:


Balance Model Comparison
  Branch/Small Office Small Business Mid-Size Business Large Enterprise/Campus
Model 20/30/50 30 LTE One 210/310 305 380 580 710 1350 2500
Capacity
Ethernet WAN Ports 2/3/5 2 2 (GbE) 2/3 (Gbe) 3 (GbE) 3 (GbE) 5 (GbE) 7 (GbE) 13 (GbE) 12 (GbE)
Simultaneous Dual-Band 802.11a/b/g/n Wi-Fi none none 1 none none none none none none none
Embedded 4G LTE none 1 none none none none none none none none
USB WAN Modem Port1 1 1 1+ 1 1 1 1 1 1 1&
Recommended Users2 1-25 1-25 1-50 1-50 50-500 50-500 300-1000 500-2000 1000-5000 5000-20000+
Router Throughput3 100Mbps 100Mbps 1Gbps 100Mbps 200Mbps 200Mbps 400Mbps 800Mbps 1.5Gbps 8Gbps
Core Functionality
Load Balancing / Failover Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Load Balancing Algorithms4 5 5 5 7 7 7 7 7 7 7
Drop-In Mode none none none Yes Yes Yes Yes Yes Yes Yes
Inbound Load Balancing none none none Yes Yes Yes Yes Yes Yes Yes
InControl Cloud Management Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
PepVPN/SpeedFusion Functionality
PepVPN Yes% Yes Yes Yes Yes Yes Yes Yes Yes Yes
SpeedFusion Hot Failover none none none Yes none^ Yes Yes Yes Yes Yes
SpeedFusion Bandwidth Bonding5 none none none^ Yes none^ Yes Yes Yes Yes Yes
Number of PepVPN/SpeedFusion Peers 2 2 2^ 2 20^ 20 50 300 800 4000
PepVPN/SpeedFusion Throughput 30Mbps 30Mbps 30Mbps^ 30Mbps 30Mbps^ 60Mbps 80Mbps 160Mbps 350Mbps 2Gbps
IPsec/PPTP VPN Functionality
IPsec VPN (Network-to-Network)6 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Number of IPsec Tunnels 2 2 2 2 20 20 50 150 400 800
PPTP VPN Server Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Recommended PPTP VPN Users 15 15 15 15 50 50 100 200 500 1000
AP Controller Functionality
Manage Pepwave AP Series Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Maximum Number of AP Support 10 10 10 10 10/50# 10/50# 10/100# 20/250# 20/500# 20/1500#
Manage Remote AP & Multiple Config Profiles none none none none none° none° none° none° none° none°
Advanced QoS Functionality
Bandwidth Usage Monitor Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
QoS for VoIP and E-Commerce Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
User Groups Bandwidth Control none none none none Yes Yes Yes Yes Yes Yes
Web Blocking Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Hardware
LAN Ports 4 (GbE) 4 (GbE) 8 (GbE) 4 (GbE) 1 (GbE) 1 (GbE) 1 (GbE) 1 (GbE) 1 (GbE) 8 (GbE)/2 (10G SFP+)*
Power Consumption 15W 15W 15W 15W 50W 50W 50W 70W 70W 230W
1U Rackmount none none none Yes Yes Yes Yes Yes Yes Yes
High Availability none none none Yes Yes Yes Yes Yes Yes Yes
LAN Bypass none none none none none none Yes Yes Yes Yes
Dual Hot Swap Power Supply none none none none none none none none none Yes
Certifications
FCC, CE, RoHS Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Warranty 1-Year Limited Warranty

1 For a list of supported modems, please refer to http://www.peplink.com/modem.
2 Recommendation for sizing purposes only. No software restrictions applied.
3 Router Throughput is based on Ethernet frame sizes of 1280 or 1518 bytes. Actual performance can vary across different networking environments.
4 Balance 20/30/50 and Balance One features Weighted, Enforced, Persistence, Priority, and Overflow Load Balancing Algorithms. Balance 210/310/305/380/580/710/1350 features Weighted, Enforced, Persistence, Priority, Overflow, Least Used, and Lowest Latency Load Balancing Algorithms.
5 Number of peer Peplink or Pepwave devices you can connect using SpeedFusion VPN.
6 IPsec only supports connection with Cisco, Juniper, Peplink or Pepwave devices.
+ Requires a future firmware scheduled to be released in June, 2014.
& Requires a future firmware scheduled to be released in second half of 2014.
^ PepVPN is supported on all models. SpeedFusion is an optional feature.
# Balance 20/30/50, Balance One and Balance 210/310/305/380/580 come with free license to manage 10 Pepwave AP devices. Balance 710/1350/2500 comes with free license to manage 20 Pepwave AP devices respectively. To manage additional AP, an optional AP Controller license purchase is required.
* Balance 30 LTE, and Balance 2500 are available different configurations. Please refer to ordering information for details.
% Balance 20/30/50 requires firmware 6.1 to support PepVPN
° All Peplink Balance come with AP Controller Standard, which supports one configuration profile with multiple SSIDs, meaning that all APs will share the same configuration, and you can only manage APs on the local physical LAN. Extra license upgrade to AP Controller Pro is required to support multiple configuration profiles with multiple SSIDs, and you can manage remote APs outside the local physical LAN.

Specifications:


Specs and Weight

Balance 20/30/50 Specs
Balance 210/310
Balance 305
Balance 380
Balance 580
Balance 710
B1350-specification
B2500-specification
Software
  • Peplink Balance Firmware
WAN
  • Support for PPPoE, Static IP, DHCP
  • WAN Link Health Check
    • PING
    • DNS Lookup
    • HTTP
  • Bandwidth Allowance Monitor
  • IPv6 Support
  • USB 4G/3G Modem Support
  • WAN port convertible into LAN port10
LAN
  • DHCP Server for LAN Clients
  • Extended DHCP Option
  • DHCP Reservation
  • Support for Dynamic DNS services
    • changeip.com
    • dyndns.org
    • no-ip.org
    • tzo.com
    • DNS-O-Matic
  • DNS Proxy for LAN Clients
  • VLAN on LAN support
Load Balancing
  • Intelligent Failover
  • Session Persistence
  • Per-Service Load Distribution
  • Multiple Algorithms
    • Weighted
    • Enforced
    • Persistence
    • Priority
    • Overflow
    • Least Used7
    • Lowest Latency7
Complete VPN Solution
  • SpeedFusion Bandwidth Bonding8
    • Site-to-Site VPN
    • Bandwidth Aggregation
    • Intelligent Failover
    • 256-bit AES Encryption
    • Pre-shared Key Authentication
    • Dynamic Routing
    • X.509 certificate support8
  • PPTP VPN Server
  • RADIUS, LDAP Authentication7
  • IPsec VPN (Network-to-Network)
    • X.509 certificate support8
Advanced QoS
  • User Groups
    • Bandwidth Reservation
    • Individual Bandwidth Limit
  • Application Prioritization
    • By User Groups
    • SIP, HTTPS, VPN QoS
    • Custom Application QoS
Networking
  • NAT and IP Forwarding
  • Static Routes
  • Port Forwarding
  • Many to One, One to One NAT
  • NAT Pool
  • SIP ALG, H.323 ALG
  • UPnP, NAT-PMP
  • WINS Server
  • OSPF and RIPv2 support
AP Controller9
  • Support for Pepwave AP Series
  • Auto AP Discovery
  • Auto AP Firmware Management
  • AP Profile Configuration
  • Wi-Fi usage statistics
Captive Portal Support9
  • Support for wired and wireless LAN clients
  • Support RADIUS authentication
  • Support LDAP authentication10
  • Time and usage quotas on Open Access mode
  • Built-in customizable splash page
DNS
  • Built-in Authoritative DNS 10
    • Support for A, CNAME, NS, MX, PTR, SOA, SRV, TXT records
Security
  • DoS Prevention
  • Stateful Firewall
  • Web Blocking
Device Management
  • Web Administrative Interface
  • Command Line Interface
  • InControl Cloud Management
  • Email Notification
  • Active Client & Session Lists
  • Bandwidth Usage Statistics
  • Syslog Service
  • SNMP v1, v2c and v3
Support and Warranty
  • 1-Year Standard Warranty
  • 1-Year Standard Support12
  • Unlimited 8×5 Email Support
  • 90 Days Telephone Support
  • 1-Year Firmware Upgrade
Power Requirements
  • Universal Input ◦100V – 240V AC
Certifications
  • CE
  • FCC
  • RoHS

7 Features not available on Balance 20/30.
8 Features available on the Balance 20/30 as an upgrade.
9 AP Controller lite comes standard with the Balance 20,30,210, and 310. AP Controller pro comes standard with the Balance 305, 380 and above.
10 This feature is only available on the Balance 305, 380 and above.
11 IPsec only supports connection with Cisco, Juniper, Peplink or Pepwave devices.
12 Only valid for customers who have purchased Peplink Balance devices directly from Peplink.

Documentation:

PDF File
Download the Peplink Balance Datasheet (PDF).
